Topaire CZ3 SmartAir+ is a smart R32 inverter air conditioner built for energy savings, cleaner air, and all-day comfort. Its DC inverter technology adjusts cooling automatically, helping you save up to RM60 a month* compared to non-star units while keeping your room perfectly cool. Enjoy fresher indoor air with the Active Carbon & Silver Ion filter, while 4-step Auto Wash keeps the evaporator clean automatically. With Gold Fin anti-corrosion protection, Turbo Cooling, ECO Gear mode, smart alerts, optional WiFi control, and a 2-year indoor / 5-year outdoor warranty, the CZ3 SmartAir+ makes modern cooling simple, efficient, and reliable.

Why Choose CZ3 SmartAir+

Key Features

• DC Inverter Compressor for energy-saving performance and stable cooling
• 5-Star & 4-Star MEPS rated (model dependent)
• 4-Step Auto Wash (Freeze, Wash, Dry, Sterilize) to keep the evaporator clean
• High-frequency start-up for faster, more powerful initial cooling
• Wide-range voltage operation (runs stably during voltage fluctuation)
• Turbo Cooling to rapidly reach your desired temperature
• 4D Airflow with auto swing (Up & Down / Left & Right) for better air distribution
• Wireless remote controller
• ECO Gear (energy-saving ECO-logic mode) for Cooling & Auto mode
• 4 operation modes: Auto, Cooling, Dry (Dehumidification), Fan Only
• 4 fan speeds: Auto, Low, Medium, High
• LED display + light indicator panel with auto restart
• Error code indication for quicker diagnosis and after-sales support
• Cleaning reminder (filter cleaning alert)
• Washable high-efficiency saran net filter with Active Carbon & Silver Ion / negative ion filtration
• Hydrophilic Aluminium Gold Fin (anti-oxidation & anti-corrosion)
• WiFi Control (Optional) via mobile app (power, temperature, fan speed)
• 2-Year Indoor / 5-Year Outdoor Warranty with nationwide spare parts and after-sales support

Choose The Right Cooling Power

• 1.0HP (10CZ3) – Bedroom / Study Room, up to 150 sq.ft.
• 1.5HP (13CZ3) – Master Bedroom / Home Office, up to 250 sq.ft.
• 2.0HP (18CZ3) – Living Room / Open Space, up to 350 sq.ft.
• 2.5HP (25CZ3) – Large Hall / Dining Area, up to 450 sq.ft.

Also suitable for condos, landed homes, boutique offices, meeting rooms, retail stores, studios and small clinics.

Technical Specifications

Specification	10CZ3	13CZ3	18CZ3	25CZ3
Horsepower	1.0HP	1.5HP	2.0HP	2.5HP
Recommended Room Size	Up to 150 sq.ft.	Up to 250 sq.ft.	Up to 350 sq.ft.	Up to 450 sq.ft.
Indoor Model	TWMV10CZ3	TWMV13CZ3	TWMV18CZ3	TWMV25CZ3
Outdoor Model	TASV10CZ3	TASV13CZ3	TASV18CZ3	TASV25CZ3
Cooling Capacity (BTU/hr)	9,000 (2,050–10,920)	12,000 (2,730–13,650)	18,000 (4,435–18,510)	24,000 (6,140–25,010)
Cooling Capacity (W)	2,640 (600–3,200)	3,550 (800–4,000)	5,280 (1,300–5,425)	7,040 (1,800–7,330)
Power Input (W)	810	1,145	1,760	2,300
Rated Current (A)	3.90	5.60	8.20	10.00
EER (W/W)	3.52	3.42	3.20	3.12
CSPF (Wh/Wh)	5.31	5.06	5.09	5.41
MEPS Star Rating
Power Supply (V/Ph/Hz)	220–240V / 1 Phase / 50Hz
Air Flow (CFM)	355	400	530	765
Sound Level – H / M / L (dB(A))	39 / 35 / 34	39 / 35 / 33	43 / 36 / 33	46 / 37 / 35
Indoor Dimensions (W×H×D mm)	768 × 298 × 201	827 × 298 × 201	997 × 321 × 222	1105 × 335 × 229
Indoor Net Weight (kg)	7.5	8.5	11.5	13.0
Pipe Size – Liquid (mm/in)	6.35 (1/4")	6.35 (1/4")	6.35 (1/4")	6.35 (1/4")
Pipe Size – Suction (mm/in)	9.52 (3/8")	9.52 (3/8")	12.70 (1/2")	12.70 (1/2")
Outdoor Dimensions (W×D×H mm)	705 × 279 × 530	830 × 315 × 655	830 × 315 × 655	830 × 315 × 655
Outdoor Net Weight (kg)	20.0	23.0	30.0	30.0
Refrigerant	R32

*Energy savings compared to non-star / below 4-star units, based on average usage of 8 hours/day, 30 days/month. Actual savings may vary based on usage and electricity tariff.
*Cooling performance is based on standard test conditions. Specifications are subject to change without prior notice.
*On mobile devices, swipe left or right within the table to view the complete details for each model.
